PowerBar V3 LED Module Aluminium yellow 590nm 1640lm 700mA 12x Osram Oslon SSL LEDs 11.41in/29cm (1748lm/ft)
- LED Module designed for high flux (1748 lm/ft) luminaires with lens for spot or flood lighting
- Easy to install due to simple plug & play connection system
- Can be divided at each 23.85mm segment to suit many fixture designs
The PowerBar V3 modules are compact and ultra bright, being designed for applications where a lot of light is needed per square meter, such as plant growth, medical, industry, commercial or architectural lighting. A PowerBar V3 module is 11.41" long, equipped with 12 high power LEDs and can be segmented at each LED.
Through the use of a aluminium PCB, the heat management is significantly improved. In addition, an NTC resistor is used on the module, which allows temperature monitoring via an external control unit. The PowerBar V3 strips each consist of 12 connected segments with an area of 1.12"x0.93"(28.5 x 23.85 mm) each. The LED strips can be divided with a saw, whereby each segment can also be used individually. On the first and last section, a terminal is mounted for simplified connection without soldering.
The PowerBar V3 aluminum LED bars are provided with holes that simplify the mounting of lenses. Many lenses from Ledil and Carclo, which are also available here in the shop, are compatible and thus enable a wide range of applications.
Compile your individual luminaire with our PowerBar V3 strips
With the matching accessories of our PowerBar V3 system, it is possible to assemble a complete luminaire. You have several options:
Option 1
- Powerbar V3 Heat sink 31631
- Heat conductive adhesive pad 31623
- Mounting clip 32381
- Florentina rod lens with different beam angles 32610, 32599, 32600, 32597, 32598, 32596, 30140
- Shade 30141 and Plug-in module 32615
Option 2
- Powerbar V3 Heat sink 31631
- Heat conductive adhesive pad 31623
- -Mounting clip 32381
- Plastic cover (do not use on PowerBar bars with UV LEDs) 32176
Option 3
- Powerbar V3 Heat sink 31631
- Heat conductive adhesive pad 31623
- Mounting clip 32381
- Individual lenses
Features
- You will receive a PowerBar V3 LED module equipped with 12 powerful yellow LEDs from the Osram Oslon SSL series
- Long-life LEDs from Osram
- 700mA LED module, at 29.4V
- Simple plug-and-play system
- 5 years warranty
- Divisible by each segment
- Better heat management thanks to aluminium circuit board
- Dimmable
- Constant current operation
- Optimized for lens systems
- NTC for temperature monitoring via external control unit
- Dimensions: 11.41"x1.12"x0.17" (286x28.5x4.5 mm)
- Mage in Germany
| SKU | 31608 |
|---|---|
| Weight brut (g) | 1.000000 |
| Color | Yellow |
| Luminous Flux per meter | 5734 |
| Bright like (W) | 478 |
| Luminous Flux Typ (lm) | 1640 |
| Efficacy (lm per W) | 79 |
| Power (W) | 20.58 |
| Viewing Angle | 150 |
| Warranty (months) | 60 |
| Lifetime for residential, 3h daily (yrs) | 92 |
| Product lifetime (h) | 100000 |
| Lifetime for commercial, 12h daily (yrs) | 23 |
| Forward Current Max | 700 |
| Wavelenght | 590 |
| Manufacturer Product Code | 31608 |
| Product Family | PowerBar V3 LED Strip |
| Strip Type | Rigid |
| LEDs number per sales unit | 49 |
| Dimensions | 286x28.5x4.55 |
| Dimensions: Length (cm) | 28.6 |
| Dimensions: Width (mm) | 28.5 |
| Dimensions: Height (mm) | 4.5 |
| Brand | Lumistrips |
| Manufacturer Part Number | 4260127453431 |
| Forward Voltage Typ (V) | 29.4 |
| Availability beyond shown stock: | NO |
